Description
GMC-Canyon Crew Cab Short Box Elevation 4WD
Specifications
Manufacturer
GMC
Model
Canyon Crew Cab Short Box Elevation 4WD
Year
2025
Category
Vans
Subcategory
Canyon
Front Head Room
40.30 in
Front Leg Room
45.20 in
Front Shoulder Room
57.40 in
Front Hip Room
54.70 in
Second Head Room
38.30 in
Second Leg Room
34.70 in
Second Shoulder Room
56.10 in
Second Hip Room
53.10 in
Wheelbase
131.00 in
Length, Overall
213.20 in
Width, Max w/o mirrors
72.40 in
Height, Overall
79.80 in
Overhang, Front
34.50 in
Overhang, Rear w/o bumper
47.30 in
Cab to Axle
23.40 in
Ground Clearance, Front
9.60 in
Ground Clearance, Rear
9.60 in
Cargo Box Length @ Floor
61.70 in
Cargo Box Width @ Floor
58.10 in
Cargo Box Width @ Wheelhousings
45.50 in
Cargo Volume
41.90 ft³
Gross Axle Weight Rating
7,100 lbs
Curb Weight
4,321 lbs
Reserve Axle Capacity
2,429 lbs
Gross Vehicle Weight Rating
6,250 lbs
As Spec'd Curb Weight
4,321 lbs
As Spec'd Payload
1,929 lbs
Base Trim Weight - Front
2,383 lbs
Base Trim Weight - Rear
1,938 lbs
Curb Weight - Front
2,383 lbs
Curb Weight - Rear
1,938 lbs
Gross Axle Wt Rating - Front
3,500 lbs
Gross Axle Wt Rating - Rear
3,600 lbs
Gross Combined Wt Rating
13,250 lbs
Maximum Payload Capacity
1,929 lbs
Reserve Axle Capacity - Front
1,117 lbs
Reserve Axle Capacity - Rear
1,312 lbs
Trim Curb Weight
4,321 lbs
Passenger Capacity
5
Fuel Tank Capacity, Approx
21.4 gal
